51C160 Motor Danfoss Series 51 And 51-1 Bent Axial Piston Motor
51C160 Motor Danfoss Series 51 And 51-1 Bent Axial Piston Motor
51C160 Motor Danfoss Series 51 And 51-1 Bent Axial Piston Motor
51C160 Motor Danfoss Series 51 And 51-1 Bent Axial Piston Motor
51C160 Motor Danfoss Series 51 And 51-1 Bent Axial Piston Motor
51C160 Motor Danfoss Series 51 And 51-1 Bent Axial Piston Motor

51C160 Motor Danfoss Series 51 And 51-1 Bent Axial Piston Motor

NOMINAL DISPLACEMENT:60 80 110 160 250 RATED PRESSURE:48MPa MAXIMUM PRESSURE:51MPa RATED SPEED:2200-5600r/min SPEED RANGE:2200-7000r/min

Send Inquiry
Description

Danfoss Series 51C160 Motor

The 51C160 Danfoss 51 and 51-1 Variable Displacement Axial Piston Motor has a tilt block design incorporating spherical pistons.
51C160 hydraulic motors are design to work with other devices in closed loop systems.
Which are for the transmission and control of hydraulic power.

51C160 motors have a large ratio of maximum and minimum displacements (5:1) / (160 cm3 : 32.2 cm3). All 51C160 motors start at full displacement. 51C160 motor series can operate in hydraulic systems with a high level of maximum pressure up to 510 bar, as well as speeds up to 5000 rpm. Motors have a wide range of control and adjustment devices.

The Danfoss 51 Series motors are use in crawler drive of bulldozers, on road machine installations, wheel drive or undercarriage of railway equipment, as well as in winches.

Model No. Model Code
513541 51C160-R-F1-N-E2-A2-AN-G1-NNN-080-AA-F3-03-25
5164825 51C160-R-D5-N-EQ-A2-JZ-K4-DDA-088-AA-NN-15-34
5164826 51C160-R-D5-N-EQ-A2-JZ-K4-DDA-068-AA-NN-15-34
5164828 51C160-R-D5-N-HZ-B1-AN-G0-ABA-060-AA-G0-03-00
5164829 51C160-R-D5-N-E2-A5-AN-G0-ABA-107-AA-G0-03-00
5164830 51C160-R-D5-N-EQ-A2-JZ-K4-AKB-088-AA-NN-15-34
5164831 51C160-R-D5-N-EQ-A2-JZ-K4-AKB-068-AA-NN-15-34
5164833 51C160-R-D5-N-EQ-A2-JZ-K4-AKB-044-AA-NN-15-34
517640 51C160-R-D5-N-N2-NN-NN-A0-NNN-092-AA-H0-00-00
700603 51C160-R-D5-N-HZ-B1-AN-G0-NNN-065-AA-F0-03-00
702491 51C160-A-D5-N-Y3-B1-SK-J1-ABA-032-AA-H0-F4-00
702492 51C160-A-D5-N-Y3-B1-SK-J1-NNN-032-AA-H0-F4-00
80000324 51C160-R-D5-N-L2-B1-VA-C0-ABA-032-AA-F0-B2-00
80000355 51C160-R-D5-N-N2-NN-NN-A0-NNN-080-AA-NN-00-00
80000475 51C160-R-D4-N-HZ-B1-AE-C2-NNN-032-AA-NN-03-00
80001884 51C160-R-D5-N-EQ-A2-JZ-K4-ACM-068-AA-NN-15-34
80002176 51C160-R-D5-N-HZ-B1-AN-G0-NNN-047-AA-G0-03-00
80002177 51C160-R-F1-N-L2-B1-VA-J1-ACN-068-AA-NN-B2-00
80002224 51C160-R-D5-N-L2-B1-VA-J1-ACN-068-AA-NN-B2-00
80002322 51C160-A-D5-N-N2-NN-NN-A0-NNN-107-AA-G3-00-00
80003764 51C160-R-D5-N-L2-B2-VA-H7-ACB-032-AA-F0-B2-00
80005707 51C160-R-D5-N-HS-A2-CH-E1-NNN-040-AA-F3-16-30
80006489 51C160-R-D4-N-HZ-B1-CN-C2-NNN-080-AA-NN-15-00
83001321 51C160-R-D4-N-HS-A2-CH-E1-NNN-107-AA-NN-16-21
83002858 51C160-R-D5-N-L2-B1-VA-C2-AKB-044-AA-NN-B2-00
83004038 51C160-R-D5-N-HZ-B1-AN-G0-NNN-080-AA-F0-03-00
83005496 51C160-R-D5-N-T2-C0-LN-G0-NNN-040-AA-F3-00-C0
83006421 51C160-A-D5-N-HZ-B1-CH-C2-ACM-032-AA-NN-20-00
83006997 51C160-R-D5-N-L2-B1-VA-J2-NNN-050-AA-F0-B2-00
83007034 51C160-A-D5-N-HZ-B1-A-N-G0-NNN-080-AA-NN-03-00
83012308 51C160-R-D4-N-Y8-B1-R-J-J1-ACM-045-AA-G3-C2-00
83012939 51C160-R-D5-N-EF-B1-V-A-C2-ACR-032-AA-G0-B2-00
83019632 51C160-R-D5-N-HZ-B1-B-E-G5-ABA-060-AA-G0-10-00
83024797 51C160-R-D5-N-L2-B1-V-A-M3-NNN-092-AA-H0-B2-00
83024855 51C160-R-D5-N-L4-B1-V-A-M3-NNN-092-AA-H0-B2-00
