51D080 Motor Danfoss Series 51 And 51-1 Bent Axial Piston Motor

51D080 Motor Danfoss Series 51 And 51-1 Bent Axial Piston Motor

NOMINAL DISPLACEMENT:60 80 110 160 250 RATED PRESSURE:48MPa MAXIMUM PRESSURE:51MPa RATED SPEED:2200-5600r/min SPEED RANGE:2200-7000r/min

Send Inquiry

Download

Description

Danfoss Series 51D080 Motor

51D080 Danfoss Series 51 and 51-1 Variable Displacement Axial Piston Motor has a tilt block design incorporating spherical pistons.
51D080 hydraulic motors design to work with other devices in closed loop systems for the transmission and control of hydraulic power.

These motors have a large ratio of maximum and minimum displacements
(5:1) / (80 cm3 : 16.1 cm3).
All 51D080 motors start at full displacement.
They can operate in hydraulic systems with a high level of maximum pressure up to 510 bar.
As well as reach speeds up to 7000 rpm.
Motors have a wide range of control and adjustment devices.

The Danfoss 51 Series motors use in crawler drive of bulldozers, on road machine installations.
Wheel drive or undercarriage of railway equipment, as well as in winches.

Complete Model No.

Model No.	Model Code
504965	51D080-A-D2-N-J1-K1-CE-H4-NNN-022-AA-E6-20-23
509046	51D080-R-D2-N-N2-NN-NN-A0-NNN-016-AA-E6-00-00
509049	51D080-A-D3-N-N2-NN-NN-A0-NNN-016-AA-E6-00-00
509614	51D080-R-D2-N-T1-R5-LN-G0-NNN-065-AA-E6-00-B8
510323	51D080-A-D2-N-J1-K1-DE-H4-NNN-017-AA-E6-20-26
511901	51D080-R-D2-N-JA-NN-BE-K3-NNN-027-AA-A0-09-17
511958	51D080-1–A-D2-N-T7-D7-NN-X1-NNN-019-AA-20-00-23
515480	51D080-1–A-D3-N-T7-D7-NN-X1-NNN-020-AA-N4-00-25
515860	51D080-1–R-D2-N-E1-B1-NN-U1-NNN-025-AA-NN-00-00
516189	51D080-R-D2-N-JA-NN-BE-K3-NNN-034-AA-NN-09-32
516394	51D080-1–A-D2-N-T7-D7-NN-X1-NNN-019-AA-F0-00-23
517079	51D080-1–A-D2-N-T7-D7-NN-X1-NNN-020-AA-F0-00-23
517322	51D080-1–R-D3-N-E2-B1-NN-U1-NNN-040-AA-E6-00-00
517404	51D080-1–R-D3-N-B7-B3-NN-U3-ADA-045-AA-F0-00-00
517549	51D080-1–H-D3-N-B7-B3-NN-U3-ADJ-023-AA-F0-00-00
517585	51D080-1–H-D3-N-B7-B3-NN-U3-AKA-032-AA-F0-00-00
518451	51D080-1–R-D3-N-E2-B1-NN-U1-NNN-032-AA-E6-00-00
518616	51D080-1–A-D2-N-T2-D2-NN-X1-NNN-018-AA-E6-00-30
518754	51D080-1–A-D3-N-P7-P7-NN-X1-NNN-040-AA-E4-00-AA
518800	51D080-1–A-D2-N-P7-P7-NN-X1-NNN-020-AA-E4-00-AA
519075	51D080-1–A-C6-N-V9-B3-NN-U5-AMB-049-AA-A3-00-00
519292	51D080-W-D3-N-Y7-B1-SL-J1-AWB-M16-AA-F0-F4-00
520984	51D080-1–H-D3-N-B7-B3-NN-U3-AWG-036-AA-F0-00-00
521194	51D080-1–A-D3-N-T7-L5-NN-X1-NNN-037-AA-F0-00-25
521228	51D080-1–A-C6-N-V0-B3-NN-U5-AMB-049-AA-A3-00-00
521455	51D080-1–R-D2-A-TA-C2-NN-X1-NNN-038-AA-NN-00-13
521489	51D080-A-D2-N-HE-B2-CE-H7-ACA-041-AA-G0-12-00
700379	51D080-1–A-D2-N-P7-P7-NN-X1-NNN-022-AA-F3-00-AA
701294	51D080-R-D2-N-L1-B1-WB-J1-ABA-016-AA-F0-D4-00
701827	51D080-1–R-D2-N-B1-B3-N-N-U3-NNN-054-AA-F3-00-00
80000083	51D080-1–R-D2-N-T7-CA-N-N-X1-NNN-030-AA-F3-00-28
80000297	51D080-1–R-D3-N-E1-B1-N-N-U1-NNN-030-AA-F3-00-00
80000301	51D080-1–A-D2-N-T2-C2-N-N-X1-NNN-036-AA-E6-00-16
80000323	51D080-1–A-D2-N-P7-P7-N-N-X1-NNN-019-AA-F0-00-AA
80000341	51D080-1–A-D2-N-T7-L5-N-N-X1-NNN-040-AA-F0-00-26
80000373	51D080-1–A-D2-N-TH-R5-N-N-X1-NNN-024-AA-F0-00-29
80000599	51D080-1–A-D3-N-T7-L5-N-N-X1-NNN-054-AA-F3-00-24
80000647	51D080-A-D2-N-HS-A3-C-E-E5-NNN-045-AA-F0-12-23
80000668	51D080-1–A-D3-N-T1-CA-N-N-X1-NNN-028-AA-F0-00-23
80001056	51D080-1–R-D2-N-T7-CA-N-N-X1-AWM-047-AA-F0-00-24
80001170	51D080-1–A-D3-N-T1-D1-N-N-X1-NNN-054-AA-F3-00-25
80001386	51D080-1–A-D2-N-T1-D1-N-N-X1-NNN-054-AA-F3-00-25
80001683	51D080-1–R-D3-N-F1-B1-N-N-U1-NNN-030-AA-F0-00-00
80003182	51D080-1–R-D3-N-E2-B1-N-N-U1-NNN-045-AA-F0-00-00
80004103	51D080-A-D2-N-D7-M1-S-K-M1-NNN-039-AA-F0-F4-25
80004175	51D080-1–A-D3-N-E1-B1-N-N-U1-NNN-032-AA-F0-00-00
80004367	51D080-1–R-D2-N-E2-B1-N-N-U1-NNN-050-AA-E6-00-00
80004458	51D080-R-D2-N-HS-A2-C-E-E1-NNN-032-AA-F3-12-30
80004460	51D080-1–R-D3-N-E2-B1-N-N-U1-NNN-030-AA-E6-00-00
80004471	51D080-1–R-D3-N-F1-B1-N-N-U1-NNN-026-AA-F0-00-00
80004619	51D080-R-D3-N-HS-A2-C-H-C1-NNN-040-AA-NN-15-15
80004803	51D080-A-D3-N-J1-K1-D-E-H4-NNN-025-AA-F3-20-24
80005138	51D080-1–A-D2-N-T1-CA-N-N-X1-NNN-030-AA-E6-00-30
80005518	51D080-R-D3-N-HS-A2-C-E-E1-NNN-047-AA-NN-15-25
80005652	51D080-1–A-D2-N-T1-CA-N-N-X1-NNN-052-AA-F0-00-20
80005854	51D080-1–R-D3-N-TA-L5-N-N-X1-NNN-040-AA-NN-00-20
80005987	51D080-A-D3-N-L2-B1-V-A-C0-NNN-030-AA-E6-B2-00
80006223	51D080-1–A-D2-N-T1-D1-N-N-X1-NNN-020-AA-NN-00-29
80006378	51D080-1–A-D3-N-T1-CA-N-N-X1-NNN-030-AA-F0-00-24
83001407	51D080-1–R-D2-N-TA-C2-N-N-X1-NNN-030-AA-NN-00-20
83001444	51D080-R-D2-N-D7-M1-S-K-N2-ACA-016-AA-F3-F4-30
83001620	51D080-1–A-D3-N-N1-NN-N-N-U1-NNN-040-AA-E6-00-00
83001753	51D080-1–R-D3-N-T1-D7-N-N-X1-NNN-026-AA-F0-00-37
83001774	51D080-R-D2-N-HS-A2-B-E-E1-NNN-045-AA-F3-11-30
83001952	51D080-R-D3-N-L2-B1-V-A-C0-NNN-027-AA-NN-B2-00
83002011	51D080-1–R-D2-N-E2-B1-N-N-U1-NNN-040-AA-NN-00-00
83002599	51D080-1–R-D2-N-E2-B1-N-N-U1-NNN-025-AA-E6-00-00
83003041	51D080-R-D3-N-EQ-A2-J-Y-E1-NNN-054-AA-F3-15-29
83003453	51D080-1–R-D3-N-E1-B1-N-N-U1-ACB-035-AA-NN-00-00
83003686	51D080-1–A-D3-N-P7-P7-N-N-X1-AWM-016-AA-E6-00-AA
83004545	51D080-1–A-D3-N-N1-NN-N-N-U1-AKB-050-AA-F0-00-00
83004871	51D080-1–R-D3-N-N1-NN-N-N-U1-NNN-040-AA-NN-00-00
83005051	51D080-1–A-D2-N-P7-P7-N-N-X1-ADA-030-AA-F3-00-AA
83005400	51D080-1–R-D3-N-E2-B1-N-N-U1-NNN-032-AA-NN-00-00
83005997	51D080-1–A-D3-N-N1-NN-N-N-U1-AVB-050-AA-F0-00-00
83006498	51D080-R-D3-N-L2-B1-V-A-C0-ADA-040-AA-E6-B2-00
83009713	51D080-1–H-D3-N-T5-CA-N-N-X1-DDL-036-AA-F3-00-22
83009714	51D080-1–H-D3-N-T5-CA-N-N-X1-DDL-036-AA-F3-00-27
83009715	51D080-1–H-D3-N-T5-CA-N-N-X1-DDL-043-AA-F3-00-22
83010052	51D080-1–A-D3-N-T7-R5-N-N-X1-NNN-054-AA-F3-00-24
83010054	51D080-R-D2-N-Y7-B1-S-K-J1-ACA-022-AA-F3-F4-00
83010244	51D080-R-D2-N-HS-A2-C-H-C1-NNN-038-AA-NN-26-13
83011694	51D080-1–A-D3-N-T7-L5-N-N-X1-NNN-045-AA-F0-00-26
83011814	51D080-1–A-C6-N-V2-B3-N-N-U5-AMB-044-AA-A3-00-00
83011815	51D080-1–A-C6-N-V2-B3-N-N-U5-AMB-049-AA-A3-00-00
83011995	51D080-1–H-D3-N-T5-CA-N-N-X1-DDL-051-AA-F3-00-22
83012053	51D080-1–R-D2-N-TA-D2-N-N-X1-NNN-016-AA-G3-00-33
83014128	51D080-R-D2-N-L2-B1-V-A-G5-NNN-032-AA-NN-B2-00
83014380	51D080-1–R-C7-N-E1-B1-N-N-U1-ADA-041-AA-F0-00-00
83014506	51D080-A-D3-N-HZ-B1-B-E-G5-NNN-020-AA-E6-06-00
83014693	51D080-1–A-D2-N-T1-CA-N-N-X1-NNN-029-AA-E6-00-31
83015581	51D080-R-D3-N-HZ-B1-C-E-G0-NNN-025-AA-F0-13-00
83016712	51D080-1–R-D2-N-E2-B1-N-N-U1-NNN-025-AA-F0-00-00
83016742	51D080-A-D2-N-HZ-B1-B-H-C2-NNN-045-AA-NN-10-00
83017055	51D080-1–R-D2-A-E7-B1-N-N-U1-NNN-031-AA-F3-00-00
83017147	51D080-1–A-D2-N-E7-B1-N-N-U1-NNN-031-AA-F3-00-00
83017148	51D080-1–R-D2-N-E7-B1-N-N-U1-NNN-031-AA-F3-00-00
83017183	51D080-1–A-D3-N-T7-R5-N-N-X1-NNN-045-AA-F0-00-26
83017883	51D080-1–R-D3-N-TA-CA-N-N-X1-NNN-050-AA-F0-00-20
83019195	51D080-1–A-D2-N-P8-P8-N-N-X1-NNN-020-AA-E4-00-AA
83023504	51D080-1–A-D2-N-E2-B1-N-N-U1-NNN-040-AA-F0-00-00
