REXROTH Type DZ6DP Pressure Sequence Valve, Direct Operated DZ6DP1 DZ6DP2 DZ6DP3 DZ6DP7

Features – For subplate mounting – Connection location to DIN 24340 form A (without locating bore), (standard) – Connection location to ISO 4401-03-02-0-05 (with locating bore), (ordering code .../60) – Subplates see catalogue sheet RE 45052 (separate order) – 5 pressure stages – 4 adjustment elements, optional: • Rotary knob • Set screw with hexagon and protective cap • Lockable rotary knob with scale • Rotary knob with scale – Check valve, optional. Max. sequence pressure 25 bar = 25 Max. sequence pressure 75 bar = 75 Max. sequence pressure 150 bar = 150 Max. sequence pressure 210 bar = 210 Max. sequence pressure 315 bar = 315 2) Rotary knob = 1 Set screw with hexagon and protective cap = 2 Lockable rotary knob with scale 1) = 3 Rotary knob with scale = 7. standard type:Type Material number DZ 6 DP2-5X/25Y R900403077 DZ 6 DP2-5X/75Y R900481060 DZ 6 DP2-5X/150Y R900481061 DZ 6 DP2-5X/210Y R900481062 DZ 6 DP2-5X/315YM R900513984
