Parker Hannifin 20/925339 JCB 3CX Twin Hydraulic Pump 36 + 26 CC/REV
Technical Specifications Rotation: Clockwise (looking from shaft end) Shaft: 1” Diameter 15T SAE Splined Shaft 16/32 Pitch Mounting Flange: SAE B 2 hole Front Pump Displacement: 36 cc/rev (36L/Min per 1000 rpm) Rear Pump Displacement: 26 cc/rev (26L/Min per 1000 rpm) Flange Inlet: Single 2” SAE Front Pump Outlet: 1.1/16”-12 UNF threaded Rear Pump Outlet: 7/8”-14 UNF threaded Maximum Working Pressure On Front Pump: 250 bar Maximum Working Pressure On Rear Pump: 275 bar Max. Input Shaft Torque: 460 Nm Weight: 26 KG
Shijiazhuang Baile Electromechanical Equipment Co., Ltd. is one of the leading manufacturers and suppliers of parker hannifin 20/925339 jcb 3cx twin hydraulic pump 36 + 26 cc/rev in China. With abundant experience, we warmly welcome you to wholesale high quality products at competitive price from our factory. Good service and punctual delivery are available.
Technical Specifications
Rotation: Clockwise (looking from shaft end)
Shaft: 1" Diameter 15T SAE Splined Shaft 16/32 Pitch
Mounting Flange: SAE B 2 hole
Front Pump Displacement: 36 cc/rev (36L/Min per 1000 rpm)
Rear Pump Displacement: 26 cc/rev (26L/Min per 1000 rpm)
Flange Inlet: Single 2" SAE
Front Pump Outlet: 1.1/16"-12 UNF threaded
Rear Pump Outlet: 7/8"-14 UNF threaded
Maximum Working Pressure On Front Pump: 250 bar
Maximum Working Pressure On Rear Pump: 275 bar
Max. Input Shaft Torque: 460 Nm
Weight: 26 KG
Replaces the following JCB part numbers
20/925339 - 20/925579 - 7029120006
Machine Fitment
PUMP, MAIN HYDRAULIC 36/26CCR 92HP BUILDS M0953996 3CXSM MANUAL Sideshift 9802/9800
PUMP, MAIN HYDRAULIC 36/26CCR M953996 3CX-4 Centremount 9802/9810
PUMP, MAIN HYDRAULIC 36/26CCR M953996 3CX-4T PC Precision Control (Servo)- Sideshift 9802/9830
PUMP, MAIN HYDRAULIC 36/26CCR 92HP BUILDS M0953996 3CX Sideshift 9802/9800
PUMP, MAIN HYDRAULIC 36/26CCR M953996 3CXSM 4TPC Precision Control (Servo)- Sideshift 9802/9830
PUMP, MAIN HYDRAULIC 36/26CCR 92HP BUILDS M0953996 3CX CONTRACTOR Sideshift 9802/9800
PUMP, MAIN HYDRAULIC 36/26CCR 92HP BUILDS M0953996 3CX SUPER Sideshift 9802/9800
PUMP, MAIN HYDRAULIC 36/26CCR M953996 3CXSM-4 Centremount 9802/9810
PUMP, MAIN HYDRAULIC 36/26CCR 92HP BUILDS M0953996 3CX P/S Sideshift 9802/9800
PUMP, MAIN HYDRAULIC 36/26CCR 92HP BUILDS M0953996 3CX SUPER MAN Sideshift 9802/9800
PUMP, MAIN HYDRAULIC 36/26CCR M953996 3CX-4WS PC Precision Control (Servo)- Sideshift 9802/9830
PUMP, MAIN HYDRAULIC 36/26CCR 92HP BUILDS M0953996 3CXSM Sideshift 9802/9800
PUMP, MAIN HYDRAULIC 36/26CCR 92HP BUILDS M0953996 3CX SUPER P/S Sideshift 9802/9800
PUMP, MAIN HYDRAULIC 36/26CCR 92HP BUILDS M0953996 3CXSM P/S Sideshift 9802/9800
PUMP, MAIN HYDRAULIC 36/26CCR 92HP BUILDS M0953996 3CX MANUAL Sideshift 9802/9800
PUMP, MAIN HYDRAULIC 36/26CCR M953996 4C Centremount 9802/9810
PUMP, MAIN HYDRAULIC 36/26CCR M953996 3CXSM444 SUPER Centremount 9802/9810
PUMP, MAIN HYDRAULIC 36/26CCR M953996 3CX4WSSMPC Precision Control (Servo)- Sideshift 9802/9830
