Parker Hannifin 20/925579 JCB 3CX Twin Hydraulic Pump 36 + 26 CC/REV



Technical Specifications

Rotation: Clockwise (looking from shaft end)
Shaft: 1" Diameter 15T SAE Splined Shaft 16/32 Pitch
Mounting Flange: SAE B 2 hole
Front Pump Displacement: 36 cc/rev (36L/Min per 1000 rpm)
Rear Pump Displacement: 26 cc/rev (26L/Min per 1000 rpm)

Flange Inlet: Single 2" SAE
Front Pump Outlet: 1.1/16"-12 UNF threaded
Rear Pump Outlet: 7/8"-14 UNF threaded
Maximum Working Pressure On Front Pump: 250 bar
Maximum Working Pressure On Rear Pump: 275 bar
Max. Input Shaft Torque: 460 Nm
Weight: 26 KG

Replaces the following JCB part numbers
20/925339 - 20/925579 - 332/F9029

Machine Fitment

PUMP 36/26 CCR MAIN HYDRAULIC 92 & 100 HP BUILDS 3CX-T 92 and 100hp 9812/0010

PUMP, MAIN HYDRAULIC 36/26CCR 92HP BUILDS M0953997 3CX MANUAL Sideshift 9802/9800

PUMP, MAIN HYDRAULIC 36/26CCR 92HP BUILDS M0953997 3CXSM P/S Sideshift 9802/9800

PUMP, MAIN HYDRAULIC 36/26CCR 92HP BUILDS M0953997 3CX P/S Sideshift 9802/9800

PUMP, MAIN HYDRAULIC 36/26CCR 92HP BUILDS M0953997 3CXSM Sideshift 9802/9800

PUMP, MAIN HYDRAULIC 36/26CCR 92HP BUILDS M0953997 3CXSM MANUAL Sideshift 9802/9800

PUMP, MAIN HYDRAULIC 36/26CCR 92HP BUILDS M0953997 3CX Sideshift 9802/9800

PUMP, MAIN HYDRAULIC 36/26CCR 92HP BUILDS M0953997 3CX SUPER Sideshift 9802/9800

PUMP, MAIN HYDRAULIC 36/26CCR 92HP BUILDS M0953997 3CX SUPER P/S Sideshift 9802/9800

PUMP, MAIN HYDRAULIC 36/26CCR 92HP BUILDS M0953997 3CX SUPER MAN Sideshift 9802/9800

PUMP 36/26 CCR MAIN HYDRAULIC - LAT-AM 90 HP BUILDS M1348037 214e/3C 14 Centremount Economy "e" 9812/0010





​​​​​​​​





​​​​​​​​​​​​​​​
