Parker Hannifin 919/66700 JCB Twin Hydraulic Pump

Parker Hannifin 919/66700 JCB Twin Hydraulic Pump

Technical Specifications Rotation: Counter-Clockwise (looking from shaft end) Shaft: 1.125” Diameter Parallel Keyed Shaft (28.8mm) Mounting Flange: SAE B 2 hole Front Pump Displacement: 33 cc/rev (33L/Min per 1000 rpm) Rear Pump Displacement: 29 cc/rev (29L/Min per 1000 rpm) Flange Inlet: Combined 2” SAE Front Pump Outlet: 3/4" BSPP threaded Rear Pump Outlet: 5/8” BSPP threaded Maximum Working Pressure On Front Pump: 240 bar Maximum Working Pressure On Rear Pump: 275 bar Max. Input Shaft Torque: 325 Nm Weight: 31 KG Replaces the following JCB part numbers 919/66700 - 919/66800 - 919/66900 919/71400 - 919/71500 - 919/71700 Machine Fitment PUMP, MAIN HYDRAULIC CODE 4072 M 3CX (CM) Centremount AA AB Engine 9802/9720 PUMP, MAIN HYDRAULIC CODE 4072 GEAR PUMP 3CX Sideshift AA AB Engine 9802/9730 PUMP, MAIN HYDRAULIC CODE 4072 GEAR PUMP 3CXSM Sideshift AA AB Engine 9802/9730 PUMP, MAIN HYDRAULIC CODE 4072 GEAR PUMP 3CX CONTRACTOR Sideshift AA AB Engine 9802/9730 PUMP, MAIN HYDRAULIC CODE 4072 GEAR PUMP 3CX444 SUPER Sideshift AA AB Engine 9802/9730 PUMP, MAIN HYDRAULIC M410964 4C 30 9802/9600 PUMP, MAIN HYDRAULIC M410964 3CXT 30 Sideshift 9802/9600 PUMP, MAIN HYDRAULIC M410964 4C 35 9802/9600 PUMP, MAIN HYDRAULIC M410964 4CN 30 9802/9600 PUMP, MAIN HYDRAULIC 4CN 9802/9700 PUMP, MAIN HYDRAULIC 3CX 9802/9700 PUMP, MAIN HYDRAULIC M410964 3CXHMT 30 Sideshift 9802/9600 PUMP, MAIN HYDRAULIC M410964 3CXSMT 35 Sideshift 9802/9600 PUMP, MAIN HYDRAULIC 4C 9802/9700 PUMP, MAIN HYDRAULIC M410964 3CXT 20 Sideshift 9802/9600 PUMP, MAIN HYDRAULIC M410964 3CXHMT 35 Sideshift 9802/9600 PUMP, MAIN HYDRAULIC M410964 4CN 35 9802/9600 PUMP, MAIN HYDRAULIC M410964 3CXSMT 30 Sideshift 9802/9600 PUMP, MAIN HYDRAULIC 3CX4M Military Sideshift 9802/9709 PUMP, MAIN HYDRAULIC M410964 3CXT 35 Sideshift 9802/9600 PUMP, MAIN HYDRAULIC 3CXSM 9802/9700 PUMP, MAIN HYDRAULIC M410964 3CXSMT 20 Sideshift 9802/9600

Send Inquiry

Description

Technical Specifications

Rotation: Counter-Clockwise (looking from shaft end)
Shaft: 1.125" Diameter Parallel Keyed Shaft (28.8mm)
Mounting Flange: SAE B 2 hole

Front Pump Displacement: 33 cc/rev (33L/Min per 1000 rpm)

Rear Pump Displacement: 29 cc/rev (29L/Min per 1000 rpm)

Flange Inlet: Combined 2" SAE
Front Pump Outlet: 3/4" BSPP threaded
Rear Pump Outlet: 5/8" BSPP threaded
Maximum Working Pressure On Front Pump: 240 bar
Maximum Working Pressure On Rear Pump: 275 bar
Max. Input Shaft Torque: 325 Nm

Weight: 31 KG

Replaces the following JCB part numbers
919/66700 - 919/66800 - 919/66900
919/71400 - 919/71500 - 919/71700

Machine Fitment

PUMP, MAIN HYDRAULIC CODE 4072 M 3CX (CM) Centremount AA AB Engine 9802/9720

PUMP, MAIN HYDRAULIC CODE 4072 GEAR PUMP 3CX Sideshift AA AB Engine 9802/9730

PUMP, MAIN HYDRAULIC CODE 4072 GEAR PUMP 3CXSM Sideshift AA AB Engine 9802/9730

PUMP, MAIN HYDRAULIC CODE 4072 GEAR PUMP 3CX CONTRACTOR Sideshift AA AB Engine 9802/9730

PUMP, MAIN HYDRAULIC CODE 4072 GEAR PUMP 3CX444 SUPER Sideshift AA AB Engine 9802/9730

PUMP, MAIN HYDRAULIC M410964 4C 30 9802/9600

PUMP, MAIN HYDRAULIC M410964 3CXT 30 Sideshift 9802/9600

PUMP, MAIN HYDRAULIC M410964 4C 35 9802/9600

PUMP, MAIN HYDRAULIC M410964 4CN 30 9802/9600

PUMP, MAIN HYDRAULIC 4CN 9802/9700

PUMP, MAIN HYDRAULIC 3CX 9802/9700

PUMP, MAIN HYDRAULIC M410964 3CXHMT 30 Sideshift 9802/9600
