PAKER T6H T7H Hybrid Technology Variable Piston Fixed Vane Pumps T6H20B T6H20C T6H29B T6H29C T6H29D T6H29DB

The hybrid pump is a combination of fixed displacement vane pump B, C, D cartridges combined with a variable cartridge of PV20 or PV29 piston pump. The cartridges are driven by a common shaft without coupling in between they have a large common suction port and two or three independent outlet ports: one for the piston, one or two for the vane pump Benefits/Features • Very compact • High pressure ratings • Low noise • Independent outlets for fixed and variable flow allow simultaneous cycles • Internal or external drain • Choice of controls • Wide range of acceptable fluids
