CASAPPA PLATA Series Fixed Displacement Axial Piston Pumps And Motors PLATA Pumps LFP 48·27 LFP 48·34 LFP 48·36,7 LFP 48-45,5 LFP 48-48 PLATA Motors LFM 30·22 LFM 30·26,5 LFM 30·28,5

PLATA series Fixed displacement axial piston pumps and motors swash plate design for open circuit applications. The design itself is extremely compact while integrating a number of functions, with an electrically controlled valve on the pump and antishock valves on the motor. Unidirectional pumps LFP48: displacements from 27 cm3/rev G 1.65 in3/rev to 48,2 cm3/rev G 2.94 in3/rev. Reversible motors LFM30: displacements from 22 cm3/rev G 1.34 in3/rev to 30,2 cm3/rev G 1.84 in3/rev. Max. peak pressure up to 350 bar G 5100 psi.Pumps features Three‑position electrically controlled valve with relief valve Electronic control of the rotor start‑up and stop ramps Rotation reverse with controlled delay Easy integration with the machine cabin controls Auxiliary gear pump with common suction, available with either cast‑iron or aluminium body Motors features Reversible rotation with integral antishock valves European and SAE standard mounting flanges Side or rear inlet options Compact size
