REXROTH Radial Piston Motor For Frame Integrated Drives MCR-A MCR3A, MCR5A, MCR10A, MCR15A

▶ Frame size MCR3 MCR3A160 MCR3A225 MCR3A255 MCR3A280 MCR3A325 MCR3A365 MCR3A400, MCR5 MCR5A380 MCR5A470 MCR5A520 MCR5A565 MCR5A620 MCR5A680 MCR5A750 MCR5A820, MCR10 MCR10A780 MCR10A860 MCR10A940 MCR10A1120 MCR10A1250 MCR10A1340, MCR15 MCR15A1130 MCR15A1250 MCR15A1500 MCR15A1780 MCR15A2150 ▶ Displacement 160 cc to 2150 cc ▶ Differential pressure up to 450 bar ▶ Torque output up to 13687 Nm ▶ Speed up to 875 rpm ▶ Open and closed circuits. Hydraulic motors of the type MCR-A are radial piston motors incorporating a front case mounting and splined drive shaft. A-type motors are suitable for a variety of applications either as a direct drive into a gearbox or by fitting an external component (e.g. gear pinion or chain sprocket). They are suitable for use in open or closed circuit operations.
