PARKER Fixed Displacement Bent-Axis Pumps F11 F12
F11 Small Frame Fixed Displacement Bent-Axis Pumps/Motors can be used at unusually high shaft speeds,Intermittent operating pressures to 6000 PSI (413.7 BAR)
PARKER Fixed Displacement Bent-Axis Pumps F11 F12 Series
F11 Small Frame Fixed Displacement Bent-Axis Pumps/Motors can be used at unusually high shaft speeds,Intermittent operating pressures to 6000 PSI (413.7 BAR)
Pump Performance Data
|
Model Series |
Displacement in3/rev (cc/rev) |
Continuous Pressure PSI (BAR) |
Rated Speed RPM |
Flow @ Rated RPM GPM (LPM) |
|
F11005 |
0.30 (4.9) |
5000 (350) |
4600 |
5.5 (20.8) |
|
F11006 |
0.37 (6.0) |
5000 (350) |
4200 |
6.6 (25.0) |
|
F11010 |
0.60 (9.8) |
5000 (350) |
4200 |
11 (41.6) |
|
F11012 |
0.76 (12.5 |
5000 (350) |
3850 |
12.5 (47.3) |
|
F11014 |
0.87 (14.3) |
5000 (350) |
3900 |
14 (53.0) |
|
F11019 |
1.16 (19.0) |
5000 (350) |
3500 |
17 (64.4) |
F12 Large Frame Fixed Displacement Bent-Axis Pumps is a high performance, bent axis, fixed displacement heavy-duty pump series. They can be used in numerous applications where high efficiency, high drive speeds, high pressure and indirect drives are desired. The F12 will provide high output flows in a very compact package.Intermittent operating pressures to 7000 PSI (482.6 BAR)
Pump Performance Data
|
Model Series |
Displacement in3/rev (cc/rev) |
Continuous Pressure PSI (BAR) |
Rated Speed RPM |
Flow @ Rated RPM GPM (LPM) |
|
F12-030 |
1.83 (30.0) |
6000 (420) |
3150 |
23 (87.1) |
|
F12-040 |
2.44 (40.0) |
6000 (420) |
2870 |
28 (106.0) |
|
F12-060 |
3.64 (59.6) |
6000 (420) |
2500 |
37 (140.1) |
|
F12-080 |
4.91 (80.4) |
6000 (420) |
2300 |
46 (174.1) |
|
F12-090 |
5.68 (93.0) |
6000 (420) |
2300 |
53.5 (202.5) |
|
F12-110 |
6.72 (110.1) |
6000 (420) |
2290 |
63 (238.5) |
|
F12-125 |
7.63 (125.0) |
6000 (420) |
2290 |
72 (272.5) |
|
F12-150 |
9.15 (150.0) |
5000 (350) |
3200 |
103 (389.9) |
|
F12-250 |
14.77 (242.0) |
5000 (350) |
2700 |
154 (583.0) |
