REXROTH Check Valve Type Z1S Z1S10A Z1S10B Z1S10P Z1S10TA Z1S10TB

Size Z1S10 Component series 4X Maximum operating pressure 350 bar [5076 psi] Maximum flow 100 l/min [26.4 US gpm] Features – Sandwich plate valve for use in vertical stackings – Porting pattern according to ISO 4401-05-04-0-05, ISO 4401-05-05-0-05 and NFPA T3.5.1 R2-2002 D05 – Diverse blocking functions, one- and two-channel – Perfect leak-proofness due to poppet of high-performance plastic – Corrosion-resistant housing design, optional – Suitable for different hydraulic fluids by simply exchanging the external seal rings (can be retrofitted) – Cheap exchange of the wear parts as the check valve installation kit can be ordered separately – With measuring ports, optional – Throttle check valve, optional – Amending documentation: • "Sandwich plates size 10", data sheet 48052 • "Hydraulic fluids on a mineral oil basis", data sheet 90220 • "Project planning information on HFC", upon request • "Manifolds", data sheet 48107
