REXROTH Check Valve Type Z1S Z1S6A Z1S6B Z1S6C Z1S6D Z1S6E Z1S6F Z1S6P Z1S6T

Size Z1S6 Component series 4X Maximum operating pressure 350 bar [5076 psi] Maximum flow 40 l/min [10.6 US gpm]. Sandwich plate valve for use in vertical stacking assemblies • As angled valve • As through valve – Position of ports to ISO 4401-03-02-0-05 and NFPA T3.5.1 R2-2002 D03 – Various checking functions in one or two channels – Optimum freedom from leakage through poppet made of heavy-duty plastic – Corrosion-resistant surface on request – Simple adjustment to special hydraulic fluids by changing the external seal rings – With measuring points, optional – As throttle check valve on request – Supplementary documentation: • Sandwich plates NG6, see RE 48050 • Hydraulic fluids on mineral oil basis see RE 90220
