DAIKIN RP Series Rotor Pump Variable Displacement Pump Integrated in Electric Motor RP08A RP15A RP15C RP23A RP23C RP38A RP38C

Low Noise The adoption of our own low noise technology realizes to reduce the operation noise so great as 10~15dB (in comparison with our own products) and improve the sound quality. ! Compactness The one housing structure enables it to shorten the length so much as 40% in comparison with our existing models. It results in easy handling and compactness of the machine. ! Low pulsation The pulsation has reduced by 50% in comparison with our existing models. ! High reliability Because of the hermetic structure such that the shaft is not out of the casing, it doesn’t need an oil seal and no oil leak will happen. Besides, the temperature rise in the motor coil is small due to the motor oil cooling structure. Consequently, the structure makes it possible to operate pumps in a long term overload conditions. ! Coping with CE Since these models are equipped with the terminal box of IP54 based on the International Standards (IEC34-1 and others), the models are the best suited for coping with the Europe safety standards (CE). Low pressure adjusting range 1 : 2.5~7MPa {25~70kgf/cm2} 2 : 2.5~14MPa {25~140kgf/cm2 } (6) High pressure adjusting range 1 : 2.5~7MPa {25~70kgf/cm2} 2 : 2.5~14MPa {25~140kgf/cm2} 3 : 3.5~21MPa {35~210kgf/cm2 }. Displacement volume 08 : 8.0cm3 /rev 15 : 14.8cm3 /rev 23 : 24.4cm3 /rev 38 : 37.7cm3 /rev.Voltage specifications No mark : AC200V (50/60Hz), AC220V (60Hz) X : AC230V (50Hz) Y : AC380V (50Hz), AC400V (50/60Hz) AC415V (50Hz), AC440V (60Hz) AC460V (60Hz)
