I-BOETH SS Bladder Accumulator BNXQ Series BNXQAB BNXQA

Accumulators can be installed vertically, horizontally and obliquely. When vertically or obliquelyinstalled, the oil valve must be at the bottom. in case of the applications listed below, particular positionsare recommended. Structure Type:Type BNXQA Type BNXQAB
Nominalvolume:0.4-100L
Nominalpressure:25Mpa
Connection type: L-Thread connection,F-Flang connection
Medium:Water or corrosive
liquid Tempareture:-100C-+93C

1,固定方式/TypeofMounting:
蓄能器容量在1升以下可以直接安装在管路上;在震动强烈和1升以上容量情况下建议使用本企业制造的卡籍或整套蓄能器固定组件。
Accumulators which volume is less than 1L, can be installed directly in the pipeline, For strongvibrations and volumes above 1 L, fixed with bracket or accumulator mounting sets are recommended
2氮气的充装/Charging Nitrogen:
要使蓄能器工作，必须把氮气充入到胶囊里去。氮气的充装用充气(氮)工具进行，建议使用本企业制造的CQU型充气工具，如氧气的压力不能满足(高压)能器的要求，建议使用本企业制造的氮气增压装置-CDZ型充氮车(专利产品)。
Nitrogen must be charged into the bladder before the accumulator starts to work .Charging nitrogen mustuse charging toois-CQJtype charging tool. lf nitrogen pressure does not meet the requirement of accumulatorplease use chaori CDZ type nitrogen filling vehicie
3注意事项/Caution:
蓄能器壳体上不得进行焊接和任何机械加工;蓄能器胶囊内只许充入氮气，不得使用氧气及其它可燃性和腐蚀性气体;蓄能器应安装在由溢流阀或其他安全阀的液压系统中。
Do not have welding or mechanical processing work on the accumulator shelt: Only nitrogen are allowed.Useof Oxygen,combustibie or corrosive gases is stirictly prohibited. Accumulators should be mounted in thehydraulic systems which have overflow valves or safety valves.
四、订货说明/Booking Note:
标准囊式蓄能器为:NXQA-40/31.5-F-Y。公称压力为31.5Mpa公称容积为40L，连接形式为法兰连接以及液压油为工作介质的A型。
Standard bladder accumulator:NXQA-40/31.5-F-Y.Nominal pressure:31.5MPa; Nominal volume:40LConnection Type: Flanged connection: Medium: Hydraulic liquid.
