REXROTH LC2A 2-way Cartridge Valve, Actively Controllable LC2A016 LC2A025 LC2A032 LC2A040 LC2A050 LC2A063 LC2A080 LC2A100 LC2A125

▶ Size :LC2A016 LC2A025 LC2A032 LC2A040 LC2A050 LC2A063 LC2A080 LC2A100 LC2A125 ▶ Component series 1X ▶ Maximum operating pressure 420 bar ▶ Maximum flow 17000 l/min (∆p = 10 bar) Features ▶ Actively controllable 2/2 directional cartridge valve ("two-level active logics") ▶ Modular design, flexible circuit set-up ▶ Installation bore according to ISO 7368 ▶ Energy efficiency due to flow-optimized geometry ▶ Leakage-free due to integrated shaft sealing ▶ Spool position monitoring "closed" and/or "open" or analog (can also be retrofitted) ▶ BG certification ▶ Increased operating pressure 450 bar, upon request.
