REXROTH Type Z2S22 Check Valve, Pilot Operated Z2S22 Z2S221-5X Z2S22A2-5X Z2S22B3-5X Z2S22A4-5X

Size Z2S25 Component series 5X Maximum operating pressure 315 bar [4568 psi] Maximum flow 450 l/min [118.9 US gpm] Features – Sandwich plate valve for use in vertical stackings – Porting pattern according to ISO 4401-08-08-0-05 and NFPA T3.5.1 R2-2002 D08 – For the leak-free blocking of one or two actuator ports, optionally – Different cracking pressures – Pre-opening standard – Check valve installation sets separately available – Special versions upon request – Amending documentation: • "Sandwich plates size 25", data sheet 48056 • "Hydraulic fluids on a mineral oil basis", data sheet 90220
