REXROTH Type Z4WE 4/2 And 4/3 Directional Isolator Valve Z4WE6D24-3X Z4WE6D27 Z4WEE46 Z4WEE51 Z4WEE53 Z4WEE54 Z4WEE56 Z4WEE57 Z4WE6E62 Z4WE6E63 Z4WE6E68 Z4WE6E115 Z4WE6E127 Z4WE6E129 Z4WE6E145

Size Z4WE6 Component series 3X Maximum operating pressure 315 bar Maximum flow 50 l/min Spool symbols e. g. D24, E51, E53, …; with DC or AC solenoids; see page 3 to 5 e. g. X250, X252, …; only with DC solenoids; see page 6 Direct voltage 24 V = G24 AC voltage 230 V 50/60 Hz = W230 Direct voltage 205 V = G205 1)
