YUKEN UCF1 UCF2 Feed Control Valves UCF1G-01-4-A UCF1G-01-4-B UCF1G-01-4-C UCF1G-01-8-A UCF1G-01-8-B UCF1G-01-8-C UCF1G-03-4 UCF1G-03-8 UCF2G-03-4 UCF2G-03-8 UCF1G-04-30 UCF2G-04-30

These valves are the combination of flow control valve, a deceleration valve and a check valve and used mainly for controlling rapid traverse and feed cycles machine tools. Switching from rapid traverse to feed is made by a cam operation, and fine feed control is accomplished by dial rotation regardless of pressure and oil temperature variation. Rapid return is free of cam actuation. 1. The maximum flow rates are values with the deceleration valve and the flow control valve fully open. The values in [ ] are maximum flow rates with the deceleration valve fully open and the flow control valve fully closed. 2. The values in { } are for pressures above 7 MPa (1020 PSI)
