Parker Hannifin 20/902900 JCB 3CX Twin Hydraulic Pump 33 + 29 CC/REV
Technical Specifications Rotation: Counter-Clockwise (looking from shaft end) Shaft: 1” Diameter Parallel Keyed Shaft Mounting Flange: SAE B 2 Hole Front Pump Displacement: 33 cc/rev (33L/Min per 1000 rpm) Middle Pump Displacement: 29 cc/rev (29L/Min per 1000 rpm) Inlet: Combined 2” SAE Flange Front Pump Outlet: 1 1/16”-12 UNF Threaded Rear Pump Outlet: 7/8”-14 UNF Threaded Maximum Working Pressure On Front Pump: 275 bar Maximum Working Pressure On Rear Pump: 275 bar Max. Input Shaft Torque: 325 Nm Weight: 26 KG Replaces the following JCB part numbers 20/902900 - 20/903100 - 20/912800 -7470 - 4070 - 4072 Machine Fitment PUMP, MAIN HYDRAULIC CODE 4070 3CXSM Sideshift AR AK Engine 9802/9750 PUMP, MAIN HYDRAULIC CODE 4070 GEAR PUMP 3CX Sideshift AA AB Engine 9802/9730 PUMP, MAIN HYDRAULIC CODE 4070 GEAR PUMP 3CX CONTRACTOR Sideshift AA AB Engine 9802/9730 PUMP, MAIN HYDRAULIC CODE 4070 3CX-4T Centremount AR AK Engine 9802/9760 PUMP, MAIN HYDRAULIC CODE 4070 3CX (CM) Centremount AA AB Engine 9802/9720 PUMP, MAIN HYDRAULIC CODE 4070 3CX PC Sideshift Servo AR/AK Engine 9802/9770 PUMP, MAIN HYDRAULIC CODE 4070 GEAR PUMP 3CXSM Sideshift AA AB Engine 9802/9730 PUMP, MAIN HYDRAULIC CODE 4070 3CX-4T PC Centremount Servo AR/AK Engine 9802/9780 PUMP, MAIN HYDRAULIC CODE 4070 3CX Sideshift AR AK Engine 9802/9750 PUMP, MAIN HYDRAULIC CODE 4070 3CXSM PC Sideshift Servo AR/AK Engine 9802/9770 PUMP, MAIN HYDRAULIC M410293 3CXHM 30 Sideshift 9802/9600 PUMP, MAIN HYDRAULIC M410293 3CXSM 30 Sideshift 9802/9600 PUMP, MAIN HYDRAULIC M410293 3CXHM 35 Sideshift 9802/9600 PUMP, MAIN HYDRAULIC M410293 3CX 20 Sideshift 9802/9600 PUMP, MAIN HYDRAULIC M410293 3CX 35 Sideshift 9802/9600 PUMP, MAIN HYDRAULIC M410293 3CX 30 Sideshift 9802/9600 PUMP, MAIN HYDRAULIC 3CXSM 9802/9700 PUMP, MAIN HYDRAULIC M410293 3CXT 35 Sideshift 9802/9600 PUMP, MAIN HYDRAULIC 3CX 9802/9700 PUMP, MAIN HYDRAULIC M410293 3CXSM 35 Sideshift 9802/9600 PUMP, MAIN HYDRAULIC M410293 3CXT 20 Sideshift 9802/9600 PUMP, MAIN HYDRAULIC M410293 3CXT 30 Sideshift 9802/9600
Technical Specifications
Rotation: Counter-Clockwise (looking from shaft end)
Shaft: 1" Diameter Parallel Keyed Shaft
Mounting Flange: SAE B 2 Hole
Front Pump Displacement: 33 cc/rev (33L/Min per 1000 rpm)
Middle Pump Displacement: 29 cc/rev (29L/Min per 1000 rpm)
Inlet: Combined 2" SAE Flange
Front Pump Outlet: 1 1/16"-12 UNF Threaded
Rear Pump Outlet: 7/8"-14 UNF Threaded
Maximum Working Pressure On Front Pump: 275 bar
Maximum Working Pressure On Rear Pump: 275 bar
Max. Input Shaft Torque: 325 Nm
Weight: 26 KG
Replaces the following JCB part numbers
20/902900 - 20/903100 - 20/912800 -7470 - 4070 - 4072
Machine Fitment
PUMP, MAIN HYDRAULIC CODE 4070 3CXSM Sideshift AR AK Engine 9802/9750
PUMP, MAIN HYDRAULIC CODE 4070 GEAR PUMP 3CX Sideshift AA AB Engine 9802/9730
PUMP, MAIN HYDRAULIC CODE 4070 GEAR PUMP 3CX CONTRACTOR Sideshift AA AB Engine 9802/9730
PUMP, MAIN HYDRAULIC CODE 4070 3CX-4T Centremount AR AK Engine 9802/9760
PUMP, MAIN HYDRAULIC CODE 4070 3CX (CM) Centremount AA AB Engine 9802/9720
PUMP, MAIN HYDRAULIC CODE 4070 3CX PC Sideshift Servo AR/AK Engine 9802/9770
PUMP, MAIN HYDRAULIC CODE 4070 GEAR PUMP 3CXSM Sideshift AA AB Engine 9802/9730
PUMP, MAIN HYDRAULIC CODE 4070 3CX-4T PC Centremount Servo AR/AK Engine 9802/9780
PUMP, MAIN HYDRAULIC CODE 4070 3CX Sideshift AR AK Engine 9802/9750
PUMP, MAIN HYDRAULIC CODE 4070 3CXSM PC Sideshift Servo AR/AK Engine 9802/9770
PUMP, MAIN HYDRAULIC M410293 3CXHM 30 Sideshift 9802/9600
PUMP, MAIN HYDRAULIC M410293 3CXSM 30 Sideshift 9802/9600
PUMP, MAIN HYDRAULIC M410293 3CXHM 35 Sideshift 9802/9600
PUMP, MAIN HYDRAULIC M410293 3CX 20 Sideshift 9802/9600
PUMP, MAIN HYDRAULIC M410293 3CX 35 Sideshift 9802/9600
PUMP, MAIN HYDRAULIC M410293 3CX 30 Sideshift 9802/9600
PUMP, MAIN HYDRAULIC 3CXSM 9802/9700
PUMP, MAIN HYDRAULIC M410293 3CXT 35 Sideshift 9802/9600
PUMP, MAIN HYDRAULIC 3CX 9802/9700
PUMP, MAIN HYDRAULIC M410293 3CXSM 35 Sideshift 9802/9600
PUMP, MAIN HYDRAULIC M410293 3CXT 20 Sideshift 9802/9600
PUMP, MAIN HYDRAULIC M410293 3CXT 30 Sideshift 9802/9600
