HYDRAULIC Diaphragm Accumulator GXQ SB210 SB330

Name: HYDRAULIC Diaphragm Accumulator GXQ SB210 SB330
Brand: HBOETH
SKU: 193982975

1. product name: diaphragm accumulator
2. structure: type A type B type C
3. nominal volume: 0.16L~3.5L
4. nominl pressure: 10Mpa~33Mpa

Send Inquiry

Description

HBOETH Hydraulic Diaphragm Accumulator GXQ SB210 SB330

GXQ-A-0.16L 0.25L 0.32L 0.5L 0.6L 0.75L 1L 1.4 2L 2.8L Custom made High pressure

Model code.

GXQ - # - # / # - #

1 2 3 4 5

1. product name: diaphragm accumulator

2. structure: type A type B type C

3. nominal volume: 0.16L~3.5L

4. nominl pressure: 10Mpa~33Mpa

5. medium: H-hydraulic oil R-emulsion

Operational principle.

In hydraulic system, the compression of gas medium is utilized to store the fluid. The diaphragm accumulator is based on the principle, using nitrogen as the compressible medium. The diaphragm accumulator consists of a fluid section and a gas section with the diaphragm acting as a gas-proof screen. The fluid section is connected with the hydraulic circuit, so that the diaphragm accumulator draws in the fluid and the gas is compressed when the pressure increae. When the pressure drops, the compressed gas expands and forces the stored fluid into the circuit.

Model	volume	pressure	diameter	height	thread connection
GXQ-A-0.16-33	0.16	33mPA	74	124	M14x1.5/G3/8
GXQ-A-0.32-33	0.32	33mPA	93	137	M18x1.5/G3/8
GXQ-A-0.5-33	0.5	33mPA	105	154	M18x1.5/G3/8
GXQ-A-0.75-33	0.75	33mPA	121	168	M18x1.5/G1/2
GXQ-A-1-33	1	33mPA	136	181	M18x1.5/G1/2
GXQ-A-1.4-33	1.4	33mPA	150	200	M18x1.5/G3/4
GXQ-A-2-33	2	33mPA	167	224	M18x1.5/G3/4
