Rexroth Axial Piston Variable MotorA6VM AA6VM Hydraulic Motor



Bosch Rexroth A6VM Series 6x (series 63 and series 65) motors are all-purpose high pressure motors for use in open and closed circuits.

The A6VM Series 63 motor is available in:

28 cc/rev displacement with nominal pressure, 400 bar and maximum pressure, 450 bar;

250 | 355 | 500 | 1000 cc/rev with nominal pressure, 350 bar and maximum pressure, 400 bar.

The A6VM Series 65 motor is available in displacements of: 55 |80 | 107 | 140 | 160 | 200 cc/rev with nominal pressure, 400 bar and maximum pressure 450 bar.

Other features of Bosch Rexroth A6VM Series 6x motors include:

Robust motor with long service life;

Approved for very high speeds;

Wide control range (can be swiveled to zero);

High torque;

Large variety of controls;

Optional attached flushing and boost-pressure valve;

Optional integrated or attached counterbalance valve;

Bent-axis design.





Size				28	55	80	107	140	160	200	250	355	500	1000
Series				63	65	65	65	65	65	65	63	63	63	63
Displacement		Vg max	cm³	28.1	54.8	80	107	140	1260	200	250	355	500	1000
		Vg x	cm³	18	35	51	68	88	61	76	205	300	417	1000
		Vg min	cm³	0	0	0	0	0	0	0	0	0	0	0
Nominal pressure		pnom	bar	400	400	400	400	400	400	400	350	350	350	350
Maximum pressure		pmax	bar	450	450	450	450	450	450	450	400	400	400	400
Maximum speed	at Vg max 1)	nnom	rpm	5550	4450	3900	3550	3250	3100	2900	2700	2240	2000	1600
	at Vg < Vg x	nmax	rpm	8750	7000	6150	5600	5150	4900	4600	3300	2650	2400	1600
	at Vg min	nmax 0	rpm	10450	8350	7350	6300	5750	5500	5100	3300	2650	2400	1600
Inlet flow 2)	at Vg max and nnom	qV nom	l/min	156	244	312	380	455	496	580	675	795	1000	1600
Torque	at Vg max and pnom	M	Nm	179	349	509	681	891	1019	1273	1391	1978	2785	5571
Weight (approx.)		m	kg	16	28	36	46	61	62	78	100	170	210	430
