REXROTH M-3SED10 M-4SED10 3/2 And 4/2 Directional Poppet Valve With Solenoid Actuation M-3SED10UK1X M-3SED10CK1X M-3SED10D1X M-3SED10Y1X M-4SED10UK1X M-4SED10CK1X M-4SED10D1X M-4SED10Y1X

Size :M-3SED10UK1X M-3SED10CK1X M-3SED10D1X M-3SED10Y1X M-4SED10UK1X M-4SED10CK1X M-4SED10D1X M-4SED10Y1X Component series 1X Maximum operating pressure 350 bar [5076 psi] Maximum flow 40 l/min [10.6 US gpm] Features – Direct operated directional poppet valve with solenoid actuation – Porting pattern to ISO 4401-05-04-0-05 and NFPA T3.5.1 R2-D05 – Subplates to data sheet RE 45054 (separate order) – Blocked port is leak-free closed – Reliable operation also after longer periods of standstill under pressure – Wet-pin DC solenoids with detachable coil (AC voltage possible with rectifier) – Solenoid coil can be rotated around 90° – For changing the coil, the pressure-tight chamber needs not to be opened – Electrical connection as individual connection – With concealed manual override, optional – Inductive position switches and proximity sensors (contactfree and floating), see RE 24830 – For further electrical connections, see RE 08010. DC voltage 24 V = G24 DC voltage 205 V = G205 1) DC voltage 96 V = G96. M-4SED 10 Y1X/350CG24N9K4 M-3SED 10 CK1X/350CG24N9K4 M-3SED 10 UK1X/350CG24N9K4
