LIEBHERR DPVG Series Axial Piston Pump With Variable Displacement Volume DPVG108 DPVG140 DPVG165 DPVG280
The Liebherr axial piston pump DPVG series is designedfor closed circuit operation in swash plate design. Thevariable displacement pumps are available in nominalsizes ranging from 108 to 280. The nominal pressure ofthe units is 450 bar and the maximum pressure is500 bar absolute. Thanks to a hydrostatic swash plate design, this variabledisplacement pump impresses with its high reliabilityand long service life cycle even under toughest conditions. The hydrostatic swash plate design is available in nominal sizes 140 and 280. further sizes are in development. The inverse drive with a swivel angle of 22* is very efficient and has a very high power density. The DPVG series is available with the most common controls. A through-drive - just like the configuration of two DPVGpumps to a multi-circuit pump - is possible in tandemdesign.
|
LIEBHERR DPVG Series Axial piston pump with variable displacement volume DPVG 108 DPVG 140 DPVG 165 DPVG 280 |
The Liebherr axial piston pump DPVG series is designedfor closed circuit operation in swash plate design. Thevariable displacement pumps are available in nominalsizes ranging from DPVG 108 DPVG 140 DPVG 165 DPVG 280. The nominal pressure ofthe units is 450 bar and the maximum pressure is500 bar absolute.
Thanks to a hydrostatic swash plate design, this variabledisplacement pump impresses with its high reliabilityand long service life cycle even under toughest conditions.
The hydrostatic swash plate design is available in nominal sizes 140 and 280. further sizes are in development.
The inverse drive with a swivel angle of 22* is very efficient and has a very high power density. The DPVG series is available with the most common controls.
A through-drive - just like the configuration of two DPVGpumps to a multi-circuit pump - is possible in tandemdesign.
