LIEBHERR FMV Variable Displacement Plug-in Motor (open Circuit) FMV75 FMV100 FMV140 FMV165 FMV250

This motor is mainly intended for installation in a mechanical travel drive (FAT). External brake valve can be attached to SAE port.Hydraulic two-point control Nominal pressure: 350 bar / Maximum pressure: 380 bar On request up to nom. size 75 : Nominal pressure: 420 bar / Maximum pressure: 450 bar Nominal size 75 100 140 165 250 Displacement Vg cm3 75 103.1 141.2 165.8 256.8 Max. speed at Vg max and ip = 330 bar nmax min-1 3900 3540 3160 3000 2600 Max. speed at Vg / Vg max = 0,65 and ip = 200 bar nmax min-1 5460 4950 4420 4200 3640 Flow at nmax qvmax L/min 293 365 446 497 668 Output power p = 330 bar Pmax kW 161 201 245 274 367 Output torque p = 330 bar Tmax Nm 394 542 742 871 1349 Product dimensions* (mm) 75 100 140 165 250 Splined shaft profile (internal splines) DIN 5480 tol. 9H W35x2x16 W35x2x16 W40x2x18 W45x2x21 W50x2x24 Centering diameter A tol. h8 170 190 210 230 260 Screw connecting diameter B 202 224 250 280 310 Fastening bores C 17 21 22 26 26 Splined shaft length D 40 40 45 50 63 Insertion length E 92.3 110.5 123 130 137 SAE flange connecting length F 134.2 140 155 174 188 Overall length G 175.2 188.5 199 220 238 Pressure ports SAE (6000 psi) 1" 1" 1 1/4" 1 1/4" 1 1/4" Oil leakage port M26x1.5 R 3/4" R 3/4" M33x2 M33x2
